CMT4545R-36M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Active PARALLEL CONNECTED e3 WRAPAROUND signal transformer ±20% 0.001MHz 536mOhm 0.250 6.35mm
PDF
/
Inventory: 7269
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Tape & Reel (TR)
Published 2005
Series CMT4545R
Size / Dimension 0.450Lx0.450W 11.43mmx11.43mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Resistance 536mOhm
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 2
Depth 15.47mm
Inductance 300 μH
Test Frequency 0.001MHz
Inductor Application POWER INDUCTOR
Terminal Placement ON CIRCLE
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 536mOhm
Rated Current-Max 0.75A
Special Feature PARALLEL CONNECTED
Inductance - Parallel 300 μH
Inductance - Series 1.2 mH
Number of Coils 2
DC Resistance (DCR) - Series 2.144Ohm
Current Rating - Series 380mA
Current Rating - Parallel 750mA
Inductance - Connected In Series 1.2mH
Dimensions
Height 0.250 6.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
