4448R-16L
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Active PARALLEL CONNECTED e3 ONE SURFACE Signal Transformer -55C~125C ±15% 0.01MHz 57mOhm Max
PDF
/
Inventory: 8535
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Shape/Size Description RECTANGULAR PACKAGE
Core Material Ferrite
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series 4448R
Size / Dimension 0.530Lx0.530W 13.46mmx13.46mm
Tolerance ±15%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 5A (24 Hours)
Number of Terminations 4
Termination SMD/SMT
ECCN Code EAR99
Resistance 57mOhm
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 2
Depth 13.71mm
Construction Rectangular
Inductance 15 μH
Test Frequency 0.01MHz
Max DC Current 2.3A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 5450
DC Resistance (DCR) - Parallel 57mOhm Max
Special Feature PARALLEL CONNECTED
Inductance - Parallel 15 μH
Inductance - Series 60 μH
Number of Coils 2
DC Resistance (DCR) - Series 228mOhm Max
Current Rating - Series 1.15A
Current Rating - Parallel 2.3A
Dimensions
Height 0.310 7.87mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
