4448-112M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Active PARALLEL CONNECTED e3 ONE SURFACE signal transformer -55C~125C ±20% 0.01MHz 19mOhm Max
PDF
/
Inventory: 4163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Shape/Size Description RECTANGULAR PACKAGE
Core Material Ferrite
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2002
Series 4448
Size / Dimension 0.530Lx0.530W 13.46mmx13.46mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 5A (24 Hours)
Number of Terminations 4
Termination SMD/SMT
ECCN Code EAR99
Resistance 19mOhm
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding NO
Number of Functions 2
Depth 13.71mm
Construction Rectangular
Inductance 8 μH
Test Frequency 0.01MHz
Max DC Current 3.5A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 5450
DC Resistance (DCR) - Parallel 19mOhm Max
Special Feature PARALLEL CONNECTED
Inductance - Parallel 8 μH
Inductance - Series 32 μH
Number of Coils 2
DC Resistance (DCR) - Series 76mOhm Max
Current Rating - Series 1.75A
Current Rating - Parallel 3.5A
Dimensions
Height 0.310 7.87mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
