EEF-UD0K680ER
RoHS
/
Package 2917 (7343 Metric)
Category Capacitors / Aluminum - Polymer Capacitors
Description
2917 (7343Metric) SP-Cap UD 8V 68muF ±20% 0.287Lx0.169W 7.30mmx4.30mm
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 1815
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2917 (7343 Metric)
Terminal Shape WRAPAROUND
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2013
Series SP-Cap UD
Size / Dimension 0.287Lx0.169W 7.30mmx4.30mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Polymer
Terminal Finish Tin (Sn)
Applications General Purpose
Capacitance 68μF
Voltage - Rated DC 8V
Packing Method BULK
Depth 4.3mm
Case Code (Metric) 7343
Case Code (Imperial) 2917
ESR (Equivalent Series Resistance) 15mOhm
Polarity POLARIZED
Rated (DC) Voltage (URdc) 8V
Lifetime @ Temp 1000 Hrs @ 105°C
Leakage Current 0.0544mA
Ripple Current 3A
Life (Hours) 1000 hours
Tan Delta 0.1
Ripple Current @ High Frequency 3A @ 100kHz
Dimensions
Height 2.8mm
Height Seated (Max) 0.118 3.00mm
Length 7.3mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
