EEF-SX0D391ER
RoHS
RoHS compliant
RoHS compliantPackage 2917 (7343 Metric)
Category Capacitors / Aluminum - Polymer Capacitors
Description
2917 (7343Metric) SP-Cap SX 2V 390muF ±20% 0.287Lx0.169W 7.30mmx4.30mm
PDF
/
Buying Options
Total Price: USD $1.63
Unit Price: USD $1.628
≥1 USD $1.628
≥10 USD $1.2232
≥100 USD $1.11584
≥500 USD $0.914144
≥1000 USD $0.729608
≥3000 USD $0.643773
Inventory: 1217
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2917 (7343 Metric)
Terminal Shape WRAPAROUND
Dielectric Material Aluminium
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2011
Series SP-Cap SX
Size / Dimension 0.287Lx0.169W 7.30mmx4.30mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Polymer
Terminal Finish Tin (Sn)
Applications General Purpose
Capacitance 390μF
Voltage - Rated DC 2V
Packing Method BULK
Depth 4.3mm
Case Code (Metric) 7343
Case Code (Imperial) 2917
ESR (Equivalent Series Resistance) 9mOhm
Polarity POLARIZED
Voltage 2V
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 78μA
Ripple Current 3A
Life (Hours) 1000 hours
Ripple Current @ High Frequency 6.3A @ 100kHz
Dissipation Factor 0.06 %
Dimensions
Height 1.9mm
Height Seated (Max) 0.079 2.00mm
Length 7.3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
