EEF-SL0E101ER
RoHS
/
Package 2917 (7343 Metric)
Category Capacitors / Aluminum - Polymer Capacitors
Description
SP-Cap SL 2917 (7343Metric) Aluminum Polymer Capacitor 0.287Lx0.169W 7.30mmx4.30mm ±20% 100muF 2.5V
PDF
/
Buying Options
Total Price: USD $7.9
Unit Price: USD $7.9002
≥1 USD $7.9002
≥10 USD $6.4828
≥100 USD $6.2795
≥500 USD $6.07715
≥1000 USD $5.8748
Inventory: 14004
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2917 (7343 Metric)
Terminal Shape WRAPAROUND
Surface Mount Land Size 0.287Lx0.169W 7.30mmx4.30mm
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2006
Series SP-Cap SL
Size / Dimension 0.287Lx0.169W 7.30mmx4.30mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Polymer
Resistance 9mOhm
Applications General Purpose
Capacitance 100μF
Voltage - Rated DC 2.5V
Packing Method BULK
Depth 4.3mm
Case Code (Metric) 7343
Case Code (Imperial) 2917
ESR (Equivalent Series Resistance) 9mOhm
Polarity POLARIZED
Lifetime @ Temp 1000 Hrs @ 105°C
Leakage Current 25μA
Ripple Current 3A
Life (Hours) 1000 hours
Ripple Current @ High Frequency 3A @ 100kHz
Dissipation Factor 0.06 %
Dimensions
Height 1.8mm
Height Seated (Max) 0.071 1.80mm
Length 7.3mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
