EEF-FD1B150R
RoHS
/
Package 2917 (7343 Metric)
Category Capacitors / Aluminum - Polymer Capacitors
Description
2917 (7343Metric) SP-Cap FD 12.5V 15muF ±20% 0.287Lx0.169W 7.30mmx4.30mm
PDF
/
Inventory: 7835
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2917 (7343 Metric)
Terminal Shape WRAPAROUND
Surface Mount Land Size 0.287Lx0.169W 7.30mmx4.30mm
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Series SP-Cap FD
Size / Dimension 0.287Lx0.169W 7.30mmx4.30mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Polymer
Terminal Finish Tin (Sn)
Applications General Purpose
Capacitance 15μF
Voltage - Rated DC 12.5V
Packing Method BULK
Depth 4.3mm
ESR (Equivalent Series Resistance) 40mOhm
Polarity POLARIZED
Lifetime @ Temp 1000 Hrs @ 105°C
Leakage Current 0.0075mA
Ripple Current 1.4A
Life (Hours) 1000 hours
Ripple Current @ High Frequency 1.4A @ 100kHz
Dissipation Factor 0.06 %
Dimensions
Height 1.1mm
Height Seated (Max) 0.047 1.20mm
Length 7.3mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
