EEF-CX0J151R
RoHS
RoHS compliant
RoHS compliantPackage 2917 (7343 Metric)
Category Capacitors / Aluminum - Polymer Capacitors
Description
2917 (7343Metric) SP-Cap CX 6.3V 150muF ±20% 0.287Lx0.169W 7.30mmx4.30mm
PDF
/
Buying Options
Total Price: USD $1.52
Unit Price: USD $1.5224
≥1 USD $1.5224
≥10 USD $1.14224
≥100 USD $1.04192
≥500 USD $0.853512
≥1000 USD $0.681226
≥3000 USD $0.601075
Inventory: 1128
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 7.3mm
Height Seated (Max) 0.075 1.90mm
Height 1.9mm
Technical
Ripple Current (AC) 2.7A
Dissipation Factor 0.06 %
Ripple Current @ High Frequency 5.1A @ 100kHz
Life (Hours) 1000 hours
Ripple Current 2.7A
Leakage Current 94.5μA
Lifetime @ Temp 2000 Hrs @ 105°C
Voltage 6.3V
Polarity POLARIZED
ESR (Equivalent Series Resistance) 15mOhm
Case Code (Imperial) 2917
Case Code (Metric) 7343
Depth 4.3mm
Packing Method BULK
Voltage - Rated DC 6.3V
Capacitance 150μF
Applications General Purpose
Type Polymer
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.287Lx0.169W 7.30mmx4.30mm
Series SP-Cap CX
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -55°C~105°C
Physical
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 2917 (7343 Metric)
Mounting Type Surface Mount
Mount PCB, Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 18 Weeks
