EEF-CX0G221XR
RoHS
RoHS compliant
RoHS compliantPackage 2917 (7343 Metric)
Category Capacitors / Aluminum - Polymer Capacitors
Description
2917 (7343Metric) SP-Cap CX 4V 220muF ±20% 0.287Lx0.169W 7.30mmx4.30mm
PDF
/
Buying Options
Total Price: USD $1.56
Unit Price: USD $1.5576
≥1 USD $1.5576
≥10 USD $1.16688
≥100 USD $1.064272
≥500 USD $0.871904
≥1000 USD $0.695869
≥3000 USD $0.613994
Inventory: 1255
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 2917 (7343 Metric)
Terminal Shape WRAPAROUND
Dielectric Material Aluminium
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2013
Series SP-Cap CX
Size / Dimension 0.287Lx0.169W 7.30mmx4.30mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Polymer
Terminal Finish Tin (Sn)
Applications General Purpose
Capacitance 220μF
Voltage - Rated DC 4V
Packing Method BULK
Depth 4.3mm
Case Code (Metric) 7343
Case Code (Imperial) 2917
ESR (Equivalent Series Resistance) 12mOhm
Polarity Polar
Voltage 4V
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 88μA
Ripple Current 3A
Life (Hours) 1000 hours
Ripple Current @ High Frequency 5.6A @ 100kHz
Dissipation Factor 0.06 %
Ripple Current (AC) 3A
Dimensions
Height 1.9mm
Height Seated (Max) 0.075 1.90mm
Length 7.3mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
