2SEPC820MW
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum - Polymer Capacitors
Description
Radial Can OS-CON? SEPC 2.5V 820muF ±20% 0.248Dia 6.30mm
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.6248
≥1 USD $0.6248
≥10 USD $0.47168
≥100 USD $0.430496
≥500 USD $0.352704
≥1000 USD $0.291491
Inventory: 1011
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height Seated (Max) 0.354 9.00mm
Height 9mm
Diameter 6.3mm
Technical
Dissipation Factor 10 %
Ripple Current @ High Frequency 5.6A @ 100kHz
Ripple Current @ Low Frequency 280mA @ 120Hz
Tan Delta 0.1
Life (Hours) 5000 hours
Ripple Current 5.6A
Leakage Current 500μA
Lifetime @ Temp 5000 Hrs @ 105°C
Voltage 2.5V
Lead Diameter 600 μm
Lead Spacing 0.098 2.50mm
Polarity Polar
ESR (Equivalent Series Resistance) 7mOhm
Lead Pitch 2.5mm
Voltage - Rated DC 2.5V
Capacitance 820μF
Applications General Purpose
Type Polymer
Termination Radial
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±20%
Size / Dimension 0.248Dia 6.30mm
Series OS-CON?, SEPC
Published 2013
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Number of Pins 9
Terminal Shape WIRE
Package / Case Radial, Can
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
