2R5SVPT560M
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum - Polymer Capacitors
Description
OS-CON SMD 105C 20000H 2.5V 560U
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.6336
≥1 USD $0.6336
≥10 USD $0.4752
≥100 USD $0.43384
≥500 USD $0.355432
≥1000 USD $0.293814
Inventory: 1131
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Surface Mount Land Size 0.260Lx0.260W 6.60mmx6.60mm
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Series OS-CON?, SVPT
Size / Dimension 0.248Dia 6.30mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Polymer
Applications General Purpose
Voltage - Rated 2.5V
Capacitance 560μF
ESR (Equivalent Series Resistance) 16mOhm
Lifetime @ Temp 20000 Hrs @ 105°C
Ripple Current @ Low Frequency 175mA @ 120Hz
Ripple Current @ High Frequency 3.5A @ 100kHz
Dimensions
Height Seated (Max) 0.256 6.50mm
Compliance
RoHS Status ROHS3 Compliant
