16SVPC68M
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum - Polymer Capacitors
Description
Radial Can - SMD OS-CON? SVPC 16V 68muF ±20% 0.248Dia 6.30mm
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.364
≥1 USD $1.364
≥10 USD $1.02608
≥100 USD $0.936144
≥500 USD $0.766832
≥1000 USD $0.61204
Inventory: 1102
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Terminal Shape ONE SURFACE
Number of Pins 6
Dielectric Material ALUMINUM (WET)
Surface Mount Land Size 0.260Lx0.260W 6.60mmx6.60mm
Technical
Operating Temperature -55°C~105°C
Packaging Cut Tape (CT)
Published 2012
Series OS-CON?, SVPC
Size / Dimension 0.248Dia 6.30mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Polymer
Applications General Purpose
Capacitance 68μF
Voltage - Rated DC 16V
Packing Method TR
ESR (Equivalent Series Resistance) 30mOhm
Polarity Polar
Voltage 16V
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 300μA
Ripple Current 2.2A
Life (Hours) 2000 hours
Tan Delta 0.12
Ripple Current @ Low Frequency 110mA @ 120Hz
Ripple Current @ High Frequency 2.2A @ 100kHz
Dissipation Factor 12 %
Ripple Current (AC) 2.2A
Dimensions
Diameter 6.3mm
Height 5.9mm
Height Seated (Max) 0.236 6.00mm
Length 7.3mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
