RNS1E101MDN1
RoHS
/
Package Radial, Can
Category Capacitors / Aluminum - Polymer Capacitors
Description
FPCAP RNS Radial Can aluminum capacitor 0.394Dia 10.00mm ±20% 100muF 25V
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.2264
≥1 USD $2.2264
≥10 USD $1.71072
≥100 USD $1.571328
≥500 USD $1.30284
≥1000 USD $1.047499
≥3000 USD $0.916564
Inventory: 203
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial, Can
Dielectric Material ALUMINUM (DRY/SOLID)
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Series FPCAP, RNS
Size / Dimension 0.394Dia 10.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Type Polymer
Terminal Finish Tin (Sn)
Applications General Purpose
HTS Code 8532.22.00
Capacitance 100μF
Voltage - Rated DC 25V
Lead Pitch 5mm
ESR (Equivalent Series Resistance) 15mOhm
Lead Spacing 0.197 5.00mm
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 500μA
Ripple Current 4.5A
Life (Hours) 2000 hours
Ripple Current @ Low Frequency 450mA @ 120Hz
Ripple Current @ High Frequency 4.5A @ 100kHz
Dissipation Factor 0.08 %
Dimensions
Diameter 10mm
Height Seated (Max) 0.551 14.00mm
Compliance
RoHS Status RoHS Compliant
