RL80E561MDN1
RoHS
/
Package Radial
Category Capacitors / Aluminum - Polymer Capacitors
Description
ALUMINUM ELECTROLYTIC CAPACITOR Radial aluminum capacitor 20% 560muF 2.5V
PDF
/
Inventory: 6440
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Package / Case Radial
Dielectric Material ALUMINUM
Technical
Tolerance 20%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 105°C
Min Operating Temperature -55°C
HTS Code 8532.22.00
Capacitance 560μF
Voltage - Rated DC 2.5V
Packing Method Box
Terminal Pitch 3.5mm
Lead Pitch 3.5052mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
ESR (Equivalent Series Resistance) 6mOhm
Polarity Polar
Ripple Current 6.1A
Life (Hours) 2000 hours
Dissipation Factor 0.12 %
Current - Leakage 500μA
Dimensions
Height Seated (Max) 8.9916mm
Length 8mm
Compliance
RoHS Status RoHS Compliant
