RL80E102MDN1PX
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum - Polymer Capacitors
Description
FPCAP RL8 Radial Can aluminum capacitor 0.315Dia 8.00mm ±20% 1000muF 2.5V
PDF
/
Inventory: 8490
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Box (TB)
Published 2015
Series FPCAP, RL8
Size / Dimension 0.315Dia 8.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Polymer
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Voltage - Rated 2.5V
HTS Code 8532.22.00
Capacitance 1000μF
Terminal Pitch 5mm
Lead Pitch 3.5052mm
ESR (Equivalent Series Resistance) 6mOhm
Polarity Polar
Lead Spacing 0.138 3.50mm
Rated (DC) Voltage (URdc) 2.5V
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 0.625mA
Ripple Current 6.1A
Life (Hours) 2000 hours
Tan Delta 0.12
Ripple Current @ Low Frequency 610mA @ 120Hz
Ripple Current @ High Frequency 6.1A @ 100kHz
Dimensions
Diameter 8mm
Height Seated (Max) 0.354 9.00mm
Length 8mm
Compliance
RoHS Status ROHS3 Compliant
