PLV1H390MDL1TD
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum - Polymer Capacitors
Description
Radial Can PLV 50V 39muF ±20% 0.315Dia 8.00mm
PDF
/
Buying Options
Total Price: USD $1.99
Unit Price: USD $1.9888
≥1 USD $1.9888
≥10 USD $1.52768
≥100 USD $1.403776
≥500 USD $1.163976
≥1000 USD $0.935845
Inventory: 1004
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Dielectric Material ALUMINUM
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Box (TB)
Published 2009
Series PLV
Size / Dimension 0.315Dia 8.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Type Polymer
Applications General Purpose
HTS Code 8532.22.00
Capacitance 39μF
Voltage - Rated DC 50V
Terminal Pitch 3.5mm
Lead Pitch 3.5052mm
ESR (Equivalent Series Resistance) 29mOhm
Polarity Polar
Lead Spacing 0.138 3.50mm
Lifetime @ Temp 3000 Hrs @ 105°C
Leakage Current 390μA
Ripple Current 2.2A
Life (Hours) 3000 hours
Ripple Current @ High Frequency 2.2A @ 100kHz
Dissipation Factor 0.12 %
Dimensions
Diameter 8mm
Height Seated (Max) 0.472 12.00mm
Length 12mm
Compliance
RoHS Status ROHS3 Compliant
