PLS0J561MCO8
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum - Polymer Capacitors
Description
Radial Can PLS 6.3V 560muF ±20% 0.248Dia 6.30mm
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.144
≥1 USD $1.144
≥10 USD $0.86064
≥100 USD $0.785312
≥500 USD $0.64328
≥1000 USD $0.513427
≥3000 USD $0.453024
Inventory: 168
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.354 9.00mm
Height 9mm
Diameter 6.3mm
Technical
Ripple Current @ High Frequency 4.3A @ 100kHz
Tan Delta 0.08
Life (Hours) 5000 hours
Ripple Current 4.3A
Leakage Current 706μA
Lifetime @ Temp 5000 Hrs @ 105°C
Voltage 6.3V
Lead Diameter 600 μm
Lead Spacing 0.098 2.50mm
Polarity Polar
ESR (Equivalent Series Resistance) 9mOhm
Lead Pitch 2.5mm
Voltage - Rated DC 6.3V
Capacitance 560μF
HTS Code 8532.22.00
Applications General Purpose
Terminal Finish Silver (Ag)
Type Polymer
ECCN Code EAR99
Termination Radial
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Tolerance ±20%
Size / Dimension 0.248Dia 6.30mm
Series PLS
Published 2009
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Terminal Shape WIRE
Package / Case Radial, Can
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 17 Weeks
