PLS0E681MCL2
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum - Polymer Capacitors
Description
Radial Can PLS 2.5V 680muF ±20% 0.315Dia 8.00mm
PDF
/
Inventory: 4504
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2009
Series PLS
Size / Dimension 0.315Dia 8.00mm
Tolerance ±20%
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Type Polymer
Terminal Finish Silver (Ag)
Applications General Purpose
HTS Code 8532.22.00
Capacitance 680μF
Voltage - Rated DC 2.5V
Lead Pitch 3.5mm
ESR (Equivalent Series Resistance) 15mOhm
Polarity Polar
Lead Spacing 0.138 3.50mm
Lead Diameter 600 μm
Voltage 2.5V
Lifetime @ Temp 5000 Hrs @ 105°C
Leakage Current 340μA
Ripple Current 3.9A
Life (Hours) 5000 hours
Tan Delta 0.08
Ripple Current @ High Frequency 3.9A @ 100kHz
Dimensions
Diameter 8mm
Height 7mm
Height Seated (Max) 0.276 7.00mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
