MAL215846223E3
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In
Category Capacitors / Aluminum Electrolytic Capacitors
Description
158PUL-SI ALUMINUM ELECTROLYTIC CAPACITOR Radial Can - Snap-In aluminum electrolytic capacitor 1.378Dia 35.00mm ±20% 22000muF 25V
PDF
/
Inventory: 1496
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Published 2015
Series 158 PUL-SI
Size / Dimension 1.378Dia 35.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Termination Snap in
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Voltage - Rated 25V
Capacitance 22000μF
Terminal Pitch 10mm
Lead Pitch 10.0076mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
ESR (Equivalent Series Resistance) 44mOhm @ 100Hz
Lead Spacing 0.394 10.00mm
Rated (DC) Voltage (URdc) 25V
Lifetime @ Temp 5000 Hrs @ 105°C
Leakage Current 1.1mA
Ripple Current 4.83A
Polarization Polar
Life (Hours) 5000 hours
Impedance 37mOhm
Ripple Current @ Low Frequency 4.83A @ 100Hz
Dimensions
Diameter 35mm
Height 40mm
Height Seated (Max) 1.654 42.00mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
