B43601D5227M000
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - Snap-In ALUMINUM ELECTROLYTIC CAPACITOR B43601 450V 220muF ±20% 1.378Dia 35.00mm
PDF
/
Inventory: 5925
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount NO
Dielectric Material ALUMINUM (WET)
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series B43601
Size / Dimension 1.378Dia 35.00mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Applications General Purpose
Voltage - Rated 450V
Capacitance 220μF
Packing Method CARDBOARD
Terminal Pitch 10mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
ESR (Equivalent Series Resistance) 490mOhm @ 100Hz
Lead Spacing 0.394 10.00mm
Rated (DC) Voltage (URdc) 450V
Lifetime @ Temp 10000 Hrs @ 85°C
Leakage Current 0.94603mA
Polarization Polar
Impedance 700mOhm
Ripple Current @ Low Frequency 1.44A @ 100Hz
Dimensions
Diameter 35mm
Height Seated (Max) 1.063 27.00mm
Length 25mm
Compliance
RoHS Status ROHS3 Compliant
Supply Chain
Factory Lead Time 14 Weeks
