B43601B5127M80
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In
Category Capacitors / Aluminum Electrolytic Capacitors
Description
B43601 Radial Can - Snap-In aluminum electrolytic capacitor 0.984Dia 25.00mm ±20% 120muF 450V
PDF
/
Inventory: 9816
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series B43601
Size / Dimension 0.984Dia 25.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Snap in
Applications General Purpose
Voltage - Rated 450V
Capacitance 120μF
Lead Pitch 10.0076mm
ESR (Equivalent Series Resistance) 900mOhm @ 100Hz
Lead Spacing 0.394 10.00mm
Lifetime @ Temp 10000 Hrs @ 85°C
Ripple Current 1.01A
Polarization Polar
Life (Hours) 10000 hours
Impedance 1.27Ohm
Ripple Current @ Low Frequency 1.01A @ 100Hz
Dimensions
Height 25mm
Height Seated (Max) 1.071 27.20mm
Compliance
RoHS Status ROHS3 Compliant
