B43511A5108M80
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In - 4 Lead
Category Capacitors / Aluminum Electrolytic Capacitors
Description
B43511 Radial Can - Snap-In - 4Lead aluminum electrolytic capacitor 1.575Dia 40.00mm ±20% 1000muF 450V
PDF
/
Buying Options
Total Price: USD $32.64
Unit Price: USD $32.643946
≥1 USD $32.643946
≥200 USD $12.632724
≥500 USD $12.188964
≥1000 USD $11.969709
Inventory: 9314
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In - 4 Lead
Number of Pins 4
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2012
Series B43511
Size / Dimension 1.575Dia 40.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Snap in
Applications General Purpose
Voltage - Rated 450V
Capacitance 1000μF
ESR (Equivalent Series Resistance) 160mOhm @ 100Hz
Lead Spacing 0.886 22.50mm
Lifetime @ Temp 12000 Hrs @ 85°C
Ripple Current 5.8A
Polarization Polar
Impedance 160mOhm
Ripple Current @ Low Frequency 5.8A @ 100Hz
Dimensions
Diameter 40mm
Height 100mm
Height Seated (Max) 4.024 102.20mm
Compliance
RoHS Status ROHS3 Compliant
