B43510A5687M80
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In - 4 Lead
Category Capacitors / Aluminum Electrolytic Capacitors
Description
B43510 Radial Can - Snap-In - 4Lead Aluminum Electrolytic Capacitor 1.378Dia 35.00mm ±20% 680muF 450V
PDF
/
Inventory: 4769
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Radial, Can - Snap-In - 4 Lead
Number of Pins 4
Mounting Type Through Hole
Mount Through Hole
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series B43510
Size / Dimension 1.378Dia 35.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Snap in
Applications General Purpose
Voltage - Rated 450V
Capacitance 680μF
Lead Pitch 24.9936mm
ESR (Equivalent Series Resistance) 170mOhm @ 100Hz
Lead Spacing 0.984 25.00mm
Lifetime @ Temp 5000 Hrs @ 85°C
Ripple Current 3.97A
Polarization Polar
Life (Hours) 5000 hours
Impedance 230mOhm
Ripple Current @ Low Frequency 3.97A @ 100Hz
Dimensions
Diameter 35mm
Height 70mm
Height Seated (Max) 2.843 72.20mm
Compliance
RoHS Status ROHS3 Compliant
Supply Chain
Factory Lead Time 18 Weeks
