B41605A8278M009
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR B41605 63V 2700muF ±20% 0.984Dia 25.00mm
PDF
/
Inventory: 4088
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial, Can
Surface Mount NO
Terminal Shape WIRE
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -55°C~125°C
Packaging Tray
Series B41605
Size / Dimension 0.984Dia 25.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications Automotive
Voltage - Rated 63V
Additional Feature STANDARD: IEC60384-4
HTS Code 8532.22.00.20
Capacitance 2700μF
Packing Method BULK
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
ESR (Equivalent Series Resistance) 21mOhm @ 100Hz
Lead Spacing 0.331 8.40mm
Rated (DC) Voltage (URdc) 63V
Lifetime @ Temp 5000 Hrs @ 125°C
Leakage Current 1.0246mA
Polarization Polar
Impedance 12mOhm
Ripple Current @ High Frequency 8.8A @ 10kHz
Dimensions
Height Seated (Max) 1.969 50.00mm
Compliance
RoHS Status ROHS3 Compliant
