B41252C7828M
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In
Category Capacitors / Aluminum Electrolytic Capacitors
Description
B41252 ALUMINUM ELECTROLYTIC CAPACITOR Radial Can - Snap-In aluminum electrolytic capacitor 1.181Dia 30.00mm ±20% 8200muF 35V
PDF
/
Inventory: 2071
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
Surface Mount NO
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series B41252
Size / Dimension 1.181Dia 30.00mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Applications General Purpose
Voltage - Rated 35V
Capacitance 8200μF
Terminal Pitch 10mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Spacing 0.394 10.00mm
Rated (DC) Voltage (URdc) 35V
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 5.74mA
Polarization Polar
Tan Delta 0.2
Ripple Current @ Low Frequency 2.95A @ 120Hz
Dimensions
Diameter 30mm
Height Seated (Max) 1.260 32.00mm
Length 30mm
Compliance
RoHS Status ROHS3 Compliant
