63YXJ22M5X11
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can YXJ 63V 22muF ±20% 0.197Dia 5.00mm
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
≥10 USD $0.13728
≥100 USD $0.098912
≥500 USD $0.085976
≥1000 USD $0.063149
≥3000 USD $0.055854
Inventory: 31241
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height Seated (Max) 0.492 12.50mm
Height 11mm
Diameter 5mm
Technical
Ripple Current @ High Frequency 173mA @ 100kHz
Ripple Current @ Low Frequency 95.15mA @ 120Hz
Impedance 880mOhm
Life (Hours) 5000 hours
Polarization Polar
Ripple Current 173mA
Lifetime @ Temp 5000 Hrs @ 105°C
Lead Spacing 0.079 2.00mm
Lead Pitch 2mm
Voltage - Rated DC 63V
Capacitance 22μF
Applications General Purpose
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±20%
Size / Dimension 0.197Dia 5.00mm
Series YXJ
Published 2012
Packaging Bulk
Operating Temperature -40°C~105°C
Physical
Package / Case Radial, Can
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
