50THV100M10X10.5
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - SMD ALUMINUM ELECTROLYTIC CAPACITOR THV 50V 100muF ±20% 0.394Dia 10.00mm
PDF
/
Buying Options
Total Price: USD $0.82
Unit Price: USD $0.8184
≥1 USD $0.8184
≥10 USD $0.5148
≥100 USD $0.38544
≥500 USD $0.344696
Inventory: 137316
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Terminal Shape FLAT
Dielectric Material ALUMINUM (WET)
Surface Mount Land Size 0.406Lx0.406W 10.30mmx10.30mm
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series THV
Size / Dimension 0.394Dia 10.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Applications Automotive
Capacitance 100μF
Voltage - Rated DC 50V
Packing Method TR
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
ESR (Equivalent Series Resistance) 250mOhm @ 100kHz
Size Code 4141
Voltage 50V
Lifetime @ Temp 3000 Hrs @ 125°C
Leakage Current 0.05mA
Ripple Current 175mA
Polarization Polar
Life (Hours) 3000 hours
Tan Delta 0.14
Ripple Current @ Low Frequency 175mA @ 120Hz
Ripple Current @ High Frequency 350mA @ 100kHz
Ripple Current (AC) 350mA
Dimensions
Diameter 10mm
Height 10.5mm
Height Seated (Max) 0.413 10.50mm
Length 10.9mm
Width 10.3mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
