400MXC68MEFCSN20X30 image
Favorite
400MXC68MEFCSN20X30 image
Favorite

400MXC68MEFCSN20X30

Rubycon
RoHS
RoHS RoHS compliant
Package Radial, Can - Snap-In
Category Capacitors / Aluminum Electrolytic Capacitors
Description Radial Can - Snap-In ALUMINUM ELECTROLYTIC CAPACITOR MXC 400V 68muF ±20% 0.787Dia 20.00mm
PDF
/
Inventory: 4586
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 1.260 32.00mm
Height 30mm
Diameter 20mm

Technical

Ripple Current @ High Frequency 784mA @ 10kHz
Ripple Current @ Low Frequency 560mA @ 120Hz
Tan Delta 0.15
Life (Hours) 3000 hours
Polarization Polar
Ripple Current 560mA
Leakage Current 0.49477mA
Lifetime @ Temp 3000 Hrs @ 105°C
Lead Spacing 0.394 10.00mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Pitch 10.0076mm
Terminal Pitch 10mm
Voltage - Rated DC 400V
Capacitance 68μF
Applications General Purpose
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.787Dia 20.00mm
Series MXC
Published 2008
Packaging Bulk
Operating Temperature -25°C~105°C

Physical

Dielectric Material ALUMINUM (WET)
Package / Case Radial, Can - Snap-In
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 18 Weeks
