25YXH820MEFCT810X23
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
YXH Radial Can aluminum electrolytic capacitor 0.394Dia 10.00mm ±20% 820muF 25V
PDF
/
Buying Options
Total Price: USD $0.24
Unit Price: USD $0.236265
≥1 USD $0.236265
≥10 USD $0.195948
≥100 USD $0.178654
Inventory: 23
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Box (TB)
Published 2015
Series YXH
Size / Dimension 0.394Dia 10.00mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Applications General Purpose
Voltage - Rated 25V
Capacitance 820μF
Lead Pitch 5.0038mm
Lead Spacing 0.197 5.00mm
Lifetime @ Temp 7000 Hrs @ 105°C
Ripple Current 990mA
Polarization Polar
Life (Hours) 7000 hours
Impedance 42mOhm
Ripple Current @ Low Frequency 990mA @ 120Hz
Ripple Current @ High Frequency 1.65A @ 100kHz
Dimensions
Height Seated (Max) 0.984 25.00mm
Compliance
RoHS Status ROHS3 Compliant
