250WXA6.8MEFCT810X9
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
WXA Radial Can aluminum electrolytic capacitor 0.394Dia 10.00mm ±20% 6.8muF 250V
PDF
/
Inventory: 7480
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Box (TB)
Series WXA
Size / Dimension 0.394Dia 10.00mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Applications Automotive
Voltage - Rated 250V
Capacitance 6.8μF
Lead Pitch 5.0038mm
Lead Spacing 0.197 5.00mm
Lifetime @ Temp 2000 Hrs @ 105°C
Ripple Current 69mA
Polarization Polar
Life (Hours) 2000 hours
Ripple Current @ Low Frequency 69mA @ 120Hz
Ripple Current @ High Frequency 103.5mA @ 10kHz
Dimensions
Height Seated (Max) 0.413 10.50mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
