200VXR1000MEFCSN35X35
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In
Category Capacitors / Aluminum Electrolytic Capacitors
Description
VXR ALUMINUM ELECTROLYTIC CAPACITOR Radial Can - Snap-In aluminum electrolytic capacitor 1.378Dia 35.00mm ±20% 1000muF 200V
PDF
/
Buying Options
Total Price: USD $4.45
Unit Price: USD $4.445479
≥1 USD $4.445479
≥200 USD $1.721212
≥500 USD $1.660819
≥1000 USD $1.630622
Inventory: 5500
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 1.457 37.00mm
Height 35mm
Diameter 35mm
Technical
Ripple Current @ High Frequency 3.3A @ 10kHz
Ripple Current @ Low Frequency 2.2A @ 120Hz
Tan Delta 0.15
Life (Hours) 7000 hours
Polarization Polar
Ripple Current 2.2A
Leakage Current 1.34165mA
Lifetime @ Temp 7000 Hrs @ 105°C
Lead Spacing 0.394 10.00mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Pitch 10.0076mm
Terminal Pitch 10mm
Voltage - Rated DC 200V
Capacitance 1000μF
Applications General Purpose
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 1.378Dia 35.00mm
Series VXR
Published 2012
Packaging Bulk
Operating Temperature -25°C~105°C
Physical
Dielectric Material ALUMINUM (WET)
Package / Case Radial, Can - Snap-In
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 20 Weeks
