10YXH6800MEFCCE16X31.5
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
YXH ALUMINUM ELECTROLYTIC CAPACITOR Radial Can aluminum electrolytic capacitor 0.630Dia 16.00mm ±20% 6800muF 10V
PDF
/
Inventory: 8840
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series YXH
Size / Dimension 0.630Dia 16.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Applications General Purpose
Voltage - Rated 10V
Capacitance 6800μF
Terminal Pitch 7.5mm
Lead Pitch 7.493mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Spacing 0.295 7.50mm
Rated (DC) Voltage (URdc) 10V
Lifetime @ Temp 8000 Hrs @ 105°C
Leakage Current 0.68mA
Ripple Current 2.415A
Polarization Polar
Life (Hours) 8000 hours
Tan Delta 0.31
Impedance 17mOhm
Ripple Current @ Low Frequency 2.415A @ 120Hz
Ripple Current @ High Frequency 3.45A @ 100kHz
Dimensions
Diameter 16mm
Height Seated (Max) 1.319 33.50mm
Length 31.5mm
Compliance
RoHS Status ROHS3 Compliant
