100MXG1000MEFCSN22X30
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - Snap-In MXG 100V 1000muF ±20% 0.866Dia 22.00mm
PDF
/
Buying Options
Total Price: USD $3.26
Unit Price: USD $3.256
≥1 USD $3.256
≥10 USD $2.19648
≥100 USD $1.76968
≥500 USD $1.639264
≥1000 USD $1.422406
≥3000 USD $1.356916
Inventory: 300
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Published 2015
Series MXG
Size / Dimension 0.866Dia 22.00mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Applications General Purpose
Voltage - Rated 100V
Capacitance 1000μF
Reach Compliance Code unknown
Lead Pitch 10.0076mm
Lead Spacing 0.394 10.00mm
Lifetime @ Temp 3000 Hrs @ 105°C
Ripple Current 1.47A
Polarization Polar
Life (Hours) 2000 hours
Ripple Current @ Low Frequency 1.47A @ 120Hz
Ripple Current @ High Frequency 1.6905A @ 10kHz
Dimensions
Height Seated (Max) 1.260 32.00mm
Compliance
RoHS Status ROHS3 Compliant
