EEU-TA1H331B
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
TA ALUMINUM ELECTROLYTIC CAPACITOR Radial Can aluminum electrolytic capacitor 0.492Dia 12.50mm ±20% 330muF 50V
PDF
/
Buying Options
Total Price: USD $1.53
Unit Price: USD $1.5312
≥1 USD $1.5312
≥10 USD $1.15016
≥100 USD $1.049664
≥500 USD $0.859936
Inventory: 573
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.866 22.00mm
Height 20mm
Diameter 12.5mm
Technical
Ripple Current @ High Frequency 1.33A @ 100kHz
Ripple Current @ Low Frequency 864.5mA @ 120Hz
Impedance 70mOhm
Tan Delta 0.1
Life (Hours) 2000 hours
Polarization Polar
Ripple Current 1.33A
Leakage Current 0.165mA
Lifetime @ Temp 2000 Hrs @ 125°C
Lead Spacing 0.197 5.00mm
ESR (Equivalent Series Resistance) 70mOhm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Pitch 5mm
Reference Standard AEC-Q200
Packing Method AMMO PACK
Voltage - Rated DC 50V
Capacitance 330μF
Applications General Purpose
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination Radial
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.492Dia 12.50mm
Series TA
Published 2012
Packaging Tape & Box (TB)
Operating Temperature -40°C~125°C
Physical
Dielectric Material ALUMINUM (WET)
Terminal Shape WIRE
Package / Case Radial, Can
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
