EEU-FM1H331L
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR FM 50V 330muF ±20% 0.394Dia 10.00mm
PDF
/
Buying Options
Total Price: USD $0.74
Unit Price: USD $0.7392
≥1 USD $0.7392
≥10 USD $0.52008
≥100 USD $0.356488
≥500 USD $0.250166
≥1000 USD $0.218891
≥3000 USD $0.211077
Inventory: 1169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Number of Pins 2
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Published 2011
Series FM
Size / Dimension 0.394Dia 10.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications General Purpose
Capacitance 330μF
Voltage - Rated DC 50V
Voltage - Rated AC 50V
Lead Pitch 5mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Length 17mm
ESR (Equivalent Series Resistance) 22mOhm
Lead Spacing 0.197 5.00mm
Lead Diameter 600 μm
Voltage 50V
Lifetime @ Temp 5000 Hrs @ 105°C
Leakage Current 0.165mA
Ripple Current 2.15A
Polarization Polar
Life (Hours) 5000 hours
Tan Delta 0.1
Impedance 22mOhm
Ripple Current @ Low Frequency 1.505A @ 120Hz
Ripple Current @ High Frequency 2.15A @ 100kHz
Dissipation Factor 0.1 %
Dimensions
Diameter 10mm
Height 25mm
Height Seated (Max) 1.063 27.00mm
Compliance
Radiation Hardening No
REACH SVHC Yes
RoHS Status RoHS Compliant
Lead Free Lead Free
