EEU-FM1C681LB
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR FM 16V 680muF ±20% 0.315Dia 8.00mm
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.642661
≥1 USD $0.642661
≥10 USD $0.606281
≥100 USD $0.571968
≥500 USD $0.539588
≥1000 USD $0.509048
Inventory: 1117
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Box (TB)
Published 2012
Series FM
Size / Dimension 0.315Dia 8.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications General Purpose
Capacitance 680μF
Voltage - Rated DC 16V
Lead Pitch 5mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
ESR (Equivalent Series Resistance) 30mOhm
Lead Spacing 0.197 5.00mm
Lifetime @ Temp 4000 Hrs @ 105°C
Leakage Current 0.1088mA
Ripple Current 1.56A
Polarization Polar
Life (Hours) 4000 hours
Tan Delta 0.16
Impedance 30mOhm
Ripple Current @ Low Frequency 1.17A @ 120Hz
Ripple Current @ High Frequency 1.56A @ 100kHz
Dimensions
Diameter 8mm
Height 20mm
Height Seated (Max) 0.866 22.00mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
