EEE-HC0J470R
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - SMD ALUMINUM ELECTROLYTIC CAPACITOR HC 6.3V 47muF ±20% 0.197Dia 5.00mm
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
≥10 USD $0.264
≥100 USD $0.19448
≥500 USD $0.158312
≥1000 USD $0.125013
Inventory: 1096
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Terminal Shape FLAT
Dielectric Material ALUMINUM (WET)
Surface Mount Land Size 0.209Lx0.209W 5.30mmx5.30mm
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2008
Series HC
Size / Dimension 0.197Dia 5.00mm
Tolerance ±20%
JESD-609 Code e3/e6
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish TIN/TIN BISMUTH
Applications Automotive
Voltage - Rated 6.3V
Capacitance 47μF
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Rated (DC) Voltage (URdc) 6.3V
Size Code 2121
Lifetime @ Temp 3000 Hrs @ 105°C
Leakage Current 0.003mA
Polarization Polar
Tan Delta 0.3
Ripple Current @ Low Frequency 46mA @ 120Hz
Ripple Current @ High Frequency 78.2mA @ 10kHz
Dimensions
Height Seated (Max) 0.228 5.80mm
Length 6.5mm
Width 5.3mm
Compliance
RoHS Status RoHS Compliant
Ratings AEC-Q200
