EEE-HA1C221XP
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - SMD ALUMINUM ELECTROLYTIC CAPACITOR HA 16V 220muF ±20% 0.248Dia 6.30mm
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.30008
≥100 USD $0.22088
≥500 USD $0.179784
Inventory: 1192
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status RoHS Compliant
Dimensions
Length 7.7mm
Height Seated (Max) 0.303 7.70mm
Diameter 6.3mm
Technical
Ripple Current @ High Frequency 178.5mA @ 10kHz
Ripple Current @ Low Frequency 105mA @ 120Hz
Tan Delta 0.16
Polarization Polar
Leakage Current 0.0352mA
Lifetime @ Temp 1000 Hrs @ 105°C
Size Code 2626
Rated (DC) Voltage (URdc) 16V
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Capacitance 220μF
Voltage - Rated 16V
Applications Automotive
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.248Dia 6.30mm
Series HA
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Surface Mount Land Size 0.260Lx0.260W 6.60mmx6.60mm
Dielectric Material ALUMINUM
Terminal Shape FLAT
Package / Case Radial, Can - SMD
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
