EEE-FK1E100R
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - SMD ALUMINUM ELECTROLYTIC CAPACITOR FK 25V 10muF ±20% 0.157Dia 4.00mm
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.089299
≥1 USD $0.089299
≥500 USD $0.065662
≥1000 USD $0.054714
≥2000 USD $0.0502
≥5000 USD $0.046922
≥10000 USD $0.043645
≥15000 USD $0.042204
≥50000 USD $0.041501
Inventory: 1141
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Terminal Shape FLAT
Dielectric Material ALUMINUM (WET)
Surface Mount Land Size 0.169Lx0.169W 4.30mmx4.30mm
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Series FK
Size / Dimension 0.157Dia 4.00mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Applications Automotive
Voltage - Rated 25V
Additional Feature RIPPLE CURRENT IS MEASURED AT 100KHZ
HTS Code 8532.24.0020
Capacitance 10μF
Packing Method TR, 13 Inch
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Rated (DC) Voltage (URdc) 25V
Size Code 1717
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 0.0025mA
Polarization Polar
Tan Delta 0.14
Impedance 1.35Ohm
Ripple Current @ Low Frequency 67.5mA @ 120Hz
Ripple Current @ High Frequency 90mA @ 100kHz
Dimensions
Height Seated (Max) 0.240 6.10mm
Length 5.5mm
Width 4.3mm
Compliance
RoHS Status RoHS Compliant
Ratings AEC-Q200
