ECE-A1CN100U
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR SU 16V 10muF ±20% 0.197Dia 5.00mm
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3168
≥1 USD $0.3168
≥10 USD $0.20856
≥100 USD $0.125048
≥500 USD $0.083354
≥1000 USD $0.07458
≥3000 USD $0.070189
Inventory: 351
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2011
Series SU
Size / Dimension 0.197Dia 5.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications General Purpose
Capacitance 10μF
Voltage - Rated DC 16V
Lead Pitch 2mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Polarity Bipolar
Lead Spacing 0.079 2.00mm
Lead Diameter 500 μm
Voltage 16V
Lifetime @ Temp 2000 Hrs @ 85°C
Leakage Current 3mA
Ripple Current 40mA
Polarization Bi-Polar
Life (Hours) 2000 hours
Tan Delta 0.2
Ripple Current @ Low Frequency 40mA @ 120Hz
Ripple Current @ High Frequency 68mA @ 10kHz
Dissipation Factor 0.2 %
Dimensions
Diameter 5mm
Height 11mm
Height Seated (Max) 0.433 11.00mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
