ECA-1HHG471B
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR NHG 50V 470muF ±20% 0.394Dia 10.00mm
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.6952
≥1 USD $0.6952
≥10 USD $0.48576
≥100 USD $0.409376
≥500 USD $0.333344
Inventory: 1164
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Height Seated (Max) 0.866 22.00mm
Height 20mm
Diameter 10mm
Technical
Lead/Base Style Straight
Ripple Current @ High Frequency 795mA @ 100kHz
Ripple Current @ Low Frequency 530mA @ 120Hz
Tan Delta 0.12
Life (Hours) 2000 hours
Polarization Polar
Ripple Current 530mA
Leakage Current 3μA
Lifetime @ Temp 2000 Hrs @ 105°C
Voltage 50V
Lead Diameter 600 μm
Lead Spacing 0.197 5.00mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Pitch 5mm
Reference Standard AEC-Q200
Packing Method AMMO PACK
Voltage - Rated DC 50V
Capacitance 470μF
Applications General Purpose
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination Radial
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.394Dia 10.00mm
Series NHG
Packaging Tape & Box (TB)
Operating Temperature -55°C~105°C
Physical
Dielectric Material ALUMINUM
Terminal Shape WIRE
Package / Case Radial, Can
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 14 Weeks
