UPS1H100MDD
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR UPS 50V 10muF ±20% 0.197Dia 5.00mm
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.171596
≥1 USD $0.171596
≥200 USD $0.066407
≥500 USD $0.064082
≥1000 USD $0.062927
Inventory: 1253
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Dielectric Material Aluminium
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2005
Series UPS
Size / Dimension 0.197Dia 5.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications General Purpose
HTS Code 8532.22.00
Capacitance 10μF
Voltage - Rated DC 50V
Lead Pitch 2mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Spacing 0.079 2.00mm
Lead Diameter 500 μm
Voltage 50V
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 15μA
Ripple Current 120mA
Polarization Polar
Life (Hours) 2000 hours
Tan Delta 0.32
Impedance 2.1Ohm
Ripple Current @ Low Frequency 20.4mA @ 120Hz
Ripple Current @ High Frequency 120mA @ 100kHz
Dissipation Factor 0.1 %
Dimensions
Diameter 5mm
Height 11mm
Height Seated (Max) 0.492 12.50mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
