UGB1H2R2KHM
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR UGB 50V 2.2muF ±10% 0.492Dia 12.50mm
PDF
/
Inventory: 1841
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2009
Series UGB
Size / Dimension 0.492Dia 12.50mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications Audio
Voltage - Rated 50V
HTS Code 8532.22.00
Capacitance 2.2μF
Terminal Pitch 5mm
Lead Pitch 5.0038mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Polarity NON-POLARIZED
Lead Spacing 0.197 5.00mm
Rated (DC) Voltage (URdc) 50V
Lifetime @ Temp 1000 Hrs @ 85°C
Leakage Current 3.3μA
Ripple Current 820mA
Polarization Bi-Polar
Life (Hours) 1000 hours
Tan Delta 0.05
Ripple Current @ High Frequency 820mA @ 9kHz
Dimensions
Diameter 12.5mm
Height Seated (Max) 0.827 21.00mm
Length 20mm
Compliance
RoHS Status ROHS3 Compliant
