478RZM035M
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR RZM 35V 4700muF ±20% 0.709Dia 18.00mm
PDF
/
Inventory: 8688
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 1.654 42.00mm
Technical
Custom Capabilities Tape & Reel, Formed Leads, Epoxy Ends
Impedance 69mOhm
Tan Delta 0.22
Life (Hours) 3000 hours
Polarization Polar
Ripple Current 2.4A
Leakage Current 4.935mA
Lifetime @ Temp 3000 Hrs @ 105°C
Rated (DC) Voltage (URdc) 35V
Lead Spacing 0.295 7.50mm
ESR (Equivalent Series Resistance) 78mOhm @ 120Hz
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Pitch 7.493mm
Capacitance 4700μF
Voltage - Rated 35V
Applications General Purpose
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.709Dia 18.00mm
Series RZM
Published 2016
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Dielectric Material ALUMINUM (WET)
Terminal Shape WIRE
Package / Case Radial, Can
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
