338CKS050M
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR CKS 50V 3300muF ±20% 0.709Dia 18.00mm
PDF
/
Buying Options
Total Price: USD $3.26
Unit Price: USD $3.2648
≥1 USD $3.2648
≥10 USD $2.50448
≥100 USD $1.683757
≥500 USD $1.420654
≥1000 USD $1.341736
Inventory: 1121
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 1.437 36.50mm
Height 35.5mm
Diameter 500μm
Technical
Dissipation Factor 0.16 %
Ripple Current @ High Frequency 4.508A @ 100kHz
Ripple Current @ Low Frequency 3.22A @ 120Hz
Life (Hours) 2000 hours
Polarization Polar
Ripple Current 3.22A
Leakage Current 4.95mA
Lifetime @ Temp 2000 Hrs @ 85°C
Lead Spacing 0.295 7.50mm
ESR (Equivalent Series Resistance) 80.4mOhm @ 120Hz
Lead Length 15mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Pitch 7.493mm
Terminal Pitch 7.5mm
Voltage - Rated DC 50V
Capacitance 3300μF
Applications General Purpose
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.709Dia 18.00mm
Series CKS
Published 2005
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Dielectric Material ALUMINUM (WET)
Terminal Shape WIRE
Package / Case Radial, Can
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 22 Weeks
