226CKS063M
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR CKS 63V 22muF ±20% 0.197Dia 5.00mm
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.076236
≥1 USD $0.076236
≥200 USD $0.030418
≥500 USD $0.029402
≥1000 USD $0.0289
Inventory: 1153
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2005
Series CKS
Size / Dimension 0.197Dia 5.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications Bypass, Decoupling
Capacitance 22μF
Voltage - Rated DC 63V
Terminal Pitch 2mm
Lead Pitch 500μm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Length 15mm
ESR (Equivalent Series Resistance) 7.536Ohm @ 120Hz
Lead Spacing 0.079 2.00mm
Lifetime @ Temp 2000 Hrs @ 85°C
Leakage Current 0.04158mA
Ripple Current 110mA
Polarization Polar
Tan Delta 0.1
Ripple Current @ Low Frequency 115mA @ 120Hz
Ripple Current @ High Frequency 264.5mA @ 100kHz
Dissipation Factor 0.1 %
Dimensions
Diameter 500μm
Height 11mm
Height Seated (Max) 0.492 12.50mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
