106RSS035MSA
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
RSS ALUMINUM ELECTROLYTIC CAPACITOR Radial Can aluminum electrolytic capacitor 0.197Dia 5.00mm ±20% 10muF 35V
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.086862
≥1 USD $0.086862
≥200 USD $0.034659
≥500 USD $0.033501
≥1000 USD $0.032928
Inventory: 963
Minimum: 1
-
+
Technical Details
Technical
Number of Terminations 2
ECCN Code EAR99
Applications General Purpose
Voltage - Rated 35V
Capacitance 10μF
Terminal Pitch 5mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
ESR (Equivalent Series Resistance) 19.894Ohm @ 120Hz
Lead Spacing 0.079 2.00mm
Rated (DC) Voltage (URdc) 35V
Lifetime @ Temp 1000 Hrs @ 85°C
Polarization Polar
Ripple Current @ Low Frequency 45mA @ 120Hz
Ripple Current @ High Frequency 630mA @ 100kHz
Custom Capabilities Tape & Reel/Ammo Pack, Cut/Formed Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.197Dia 5.00mm
Series RSS
Published 2016
Packaging Bulk
Operating Temperature -40°C~85°C
Dimensions
Height Seated (Max) 0.315 8.00mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Dielectric Material ALUMINUM (WET)
Package / Case Radial, Can
Mounting Type Through Hole
Supply Chain
Factory Lead Time 22 Weeks
