B41456B8229M
RoHS
/
Package Radial
Category Capacitors / Aluminum Electrolytic Capacitors
Description
ALUMINUM ELECTROLYTIC CAPACITOR Radial aluminum electrolytic capacitor 20% 22mF 63V
PDF
/
Buying Options
Total Price: USD $23.89
Unit Price: USD $23.888415
≥1 USD $23.888415
≥10 USD $22.536243
≥100 USD $21.260604
≥500 USD $20.057178
≥1000 USD $18.921871
Inventory: 1225
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Length 80.7mm
Height Seated (Max) 80.6958mm
Height 80.7mm
Diameter 51.6mm
Technical
Ripple Current (AC) 11A
Impedance 16mOhm
Life (Hours) 12000 hours
Test Frequency 100Hz
Ripple Current 11A
Voltage 63V
Polarity Polar
ESR (Equivalent Series Resistance) 16mOhm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Pitch 22.2mm
Packing Method Cardboard
Voltage - Rated DC 63V
Capacitance 22mF
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Termination Screw
Number of Terminations 2
Pbfree Code yes
Tolerance 20%
Packaging Bulk
Physical
Dielectric Material Aluminium
Number of Pins 2
Terminal Shape LUG
Package / Case Radial
Mount Chassis Mount, Clamp
