DCMC104U016EB2B image
Favorite
DCMC104U016EB2B image
Favorite
RoHS
RoHS RoHS compliant
Package Radial, Can - Screw Terminals
Category Capacitors / Aluminum Electrolytic Capacitors
Description Radial Can - Screw Terminals ALUMINUM ELECTROLYTIC CAPACITOR DCMC 16V 100000muF -10% +75% 1.750Dia 44.45mm
PDF
/
Inventory: 6104
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length 80.142mm
Height Seated (Max) 3.187 80.95mm
Diameter 45.06mm

Technical

Ripple Current @ High Frequency 12.432A @ 10kHz
Ripple Current @ Low Frequency 11.1A @ 120Hz
Polarization Polar
Leakage Current 7.59mA
Lifetime @ Temp 2000 Hrs @ 85°C
Rated (DC) Voltage (URdc) 16V
Lead Spacing 0.750 19.05mm
ESR (Equivalent Series Resistance) 12.5mOhm @ 120Hz
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Terminal Pitch 19.05mm
Capacitance 100000μF
Voltage - Rated 16V
Applications General Purpose
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Tolerance -10% +75%
Size / Dimension 1.750Dia 44.45mm
Series DCMC
Packaging Bulk
Operating Temperature -40°C~85°C

Physical

Dielectric Material ALUMINUM (WET)
Terminal Shape BINDING POST
Surface Mount NO
Package / Case Radial, Can - Screw Terminals
Mounting Type Chassis Mount

Supply Chain

Factory Lead Time 13 Weeks
