PKM33EPH1202C
RoHS
/
Package Radial
Category Audio Products / Alarms, Buzzers, and Sirens
Description
Audio Indicators & Alerts 40.0nF +/-30% Sound Component
PDF
/
Inventory: 2316
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Series PiezoRinger?
Size / Dimension 1.299Dia 33.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Max Operating Temperature 70°C
Min Operating Temperature -20°C
Voltage - Rated 30V
Technology Piezo
Frequency 1.2kHz
Operating Mode Ringer
Input Type Peak-Peak Signal
Voltage Range 40V Max
Washable No
Port Location Top
Sound Pressure Level (SPL) 68dB @ 30V, 100cm
Driver Circuitry Transducer, Externally Driven
Dimensions
Diameter 33mm
Height 7.5mm
Height Seated (Max) 0.315 8.00mm
Compliance
RoHS Status RoHS Compliant
